Check the XML tree for strange clipping paths and other defs. Some can be fixed with Apply Transformations

wrong transformations (width, height, viewport) and scales.

To support great variety there are options for pre-processing the data by filtering out entities, because some tools like sk1 UniConvertor fail to make an SVG from DXF if there occure entities which it cannot handle.īelonging to your toolchain configuration beware. While making this extension i stumbled upon ezdxf library, which is a powerful python implementation to deal with AutoCAD DXF format really well.

Because there are so much different DXF versions a lot of files fail with the default DXF import tool from InkScape.

The SVG result will be pushed into InkScape. DWG files are getting converted into DXF and then the DXF gets processed into SVG. This is an extension which allows to import DWG and DXF files into InkScape (working with Linux and Windows).
